Introduction of CV-Type Side-entry mixer：
Installing a side-entry mixer in the oil tank, is used for mixing oils or other medium and then reach the purpose of harmonization, heat transfer , homogenization and prevention of sediment accumulation. Using this equipment has many advantages, such as small investment, convenient operation, high efficiency, low power consumption, low static electricity generated in medium and guarantee product quality.
CV-Type Side-entry mixer can be installed in petroleum tank, lubricating tank, fuel oil drum, paraffin tank and some storage tanks for additive and other medium which need to be stirred.
Swing Angle changes of CV-Type Side-entry mixer：
The variable insertion Angle type agitator is used to prevent the accumulation of sediments, and the change of rotation Angle as follows
Material
What is the specific method of using different side mounted agitator?
When using a side mounted agitator, we may have an accident if it is not properly operated. Therefore, we must pay attention to all aspects when using the side-in type agitator.
The shape of the side mounted agitator is combined with the purpose of mixing. Different mixing processes need to be realized by different side mounted agitator. In the design and design, the side mounted agitator type, motor power and stirring speed are determined according to the purpose and requirements of the mixing operation. Then select the reducer, frame, agitator shaft, shaft seal and other components.
The specific steps are as follows:
According to the process conditions, mixing purpose and requirements, the side-in type agitator type is selected. When selecting the side-in type agitator type, the dynamic characteristics of the side-in type agitator and the flow generated by the side-in type agitator during the agitation process should be fully grasped. The causal relationship between the state and various mixing purposes.
According to the determined flow state generated by the side-in type agitator type and the side-in type agitator during the agitation process, the control requirements of the mixing time, the sedimentation speed and the dispersion degree of the process are determined by experimental means or computer simulation design. Motor power, agitation speed, side-in type agitator diameter.
According to the motor power, stirring speed and process conditions, select the reducer model from the gearbox selection table. If the gearbox is selected according to the actual working torque, the actual working torque should be less than the allowable torque of the gearbox.
According to the output shaft head d of the reducer and the agitator shaft support mode, the frame and coupling with the same model specifications as d are selected.
The sealing form is selected according to the frame agitating shaft head d0 size, installation and accommodation space, working pressure, working temperature and process requirements.
According to the installation form and structural requirements, the design selects the structure of the stirring shaft structure, and checks the strength and steelness of the pro-calibration.
According to the nominal size of the frame DN, the type of the shaft of the stirring shaft and the pressure level, the bottom cover and flange flange are selected.
Determine whether or not to configure the auxiliary support according to the support and anti-vibration conditions.
